Uniview NVR 4-CH NVR301-04LS3-P4
$ 74
SKU: NVR301-04LS3-P4
Share To:
WhatsApp
Facebook
| NVR301-04LS3-P4 | NVR301-08LS3-P8 | NVR301-16LS3-P8 | ||||||||||
| Decoding | ||||||||||||
| Decoding Format | Ultra 265, H.265, H.264 | |||||||||||
| Decoding Capability | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30, 16 x D1@25 | |||||||||
| Decoding Capability Description | The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width | |||||||||||
| Audio Compression | G.711A, G.711U | |||||||||||
| Network | ||||||||||||
| Incoming Bandwidth | 64 Mbps | |||||||||||
| Outgoing Bandwidth | 48 Mbps | |||||||||||
| Remote Users | 128 | |||||||||||
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP, IPv4 | |||||||||||
| Browser(Plugin) | Windows: IE (IE10/ 11), Firefox (version 52.0 and above), Chrome (version 45 and above), Edge (version 79 and above) | |||||||||||
| Video/Audio Input | ||||||||||||
| IP Video Input | 4-ch | 8-ch | 16-ch | |||||||||
| Video/Audio Output | ||||||||||||
| HDMI Output | 4K(3840×2160)/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz | |||||||||||
| VGA Output | 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz | |||||||||||
| RCA Audio Output | 1-ch | |||||||||||
| Liveview Display | 1/4 | 1/4/6/8/9 | 1/4/6/8/9/16 | |||||||||
| Corridor Mode Screen | 3/4 | 3/4/5/7/9 | 3/4/5/7/9/10/12/16 | |||||||||
| Snapshot | ||||||||||||
| FTP/Schedule/Event Snapshot | 1-ch snapshot, up to D1 resolution | |||||||||||
| Recording | ||||||||||||
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF | |||||||||||
| Synchronous Playback in Local | 4-ch | 8-ch | 16-ch | |||||||||
| Smart | ||||||||||||
| VCA Detection by IPC | Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD) | |||||||||||
| VCA Search | Behavior Search | |||||||||||
| Smart by IPC | Total 4-ch(Face Detection, SIP, UMD) | |||||||||||
| Alarm | ||||||||||||
| General Alarm | Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection | |||||||||||
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | |||||||||||
| GUI Language | ||||||||||||
| GUI Language | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian | |||||||||||
| Hard Disk | ||||||||||||
| SATA | 1 SATA Interface | |||||||||||
| Capacity | Up to 10TB for each HDD(The maximum HDD capacity varies with environment temperature and hard disk size) | |||||||||||
| External Interface | ||||||||||||
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface | |||||||||||
| USB | Rear panel: 2 x USB2.0 | |||||||||||
| RS485 | N/A | |||||||||||
| RS232 | N/A | |||||||||||
| Alarm In | N/A | |||||||||||
| Alarm Out | N/A | |||||||||||
| Power Supply | DC 48V/1.35A | DC 52V/1.8A | DC 52V/1.8A | |||||||||
| PoE | ||||||||||||
| PoE Interface | 4 RJ45 10M/100M self-adaptive Ethernet Interface | 8 RJ45 10M/100M self-adaptive Ethernet Interface | 8 RJ45 10M/100M self-adaptive Ethernet Interface | |||||||||
| Max Power | Max 30W for single port, Max 54W in total | Max 30W for single port, Max 75W in total | Max 30W for single port, Max 75W in total | |||||||||
| Supported Standard | IEEE 802.3at, IEEE 802.3af | |||||||||||
| Working Environment | ||||||||||||
| Working Temperature | -10 °C ~ 55 °C (14 °F ~ 131 °F) | |||||||||||
| Working Humidity | ≤ 90% RH (non-condensing) | |||||||||||
| Power Consumption (without HDD) | ≤ 9W | |||||||||||
| Dimensions | ||||||||||||
| Weight (without HDD) | ≤ 0.6Kg (1.32lb) | ≤ 0.8Kg (1.76lb) | ≤ 0.8Kg (1.76lb) | |||||||||
| Dimensions | 205mm × 205mm × 46mm (8.1″×8.1″×1.8″) | 270mm × 205mm × 46mm (10.6″×8.1″×1.8″) | 270mm × 205mm × 46mm (10.6″×8.1″×1.8″) | |||||||||
| Certification | ||||||||||||
| Certification | CE; FCC; UL; RoHS; WEEE | |||||||||||
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 | |||||||||||
| FCC | Part15 Subpart B | |||||||||||
Brand
Uniview
Introducing UNV Providing High-end and reliable Surveillance CCTV Cameras, available at Tech Store Lebanon.
